Description
Model | C1HC (H.265) |
---|---|
Camera | |
Image Sensor | 1/3″ Progressive Scan CMOS |
Shutter Speed | Self-adaptive shutter |
Lens | 2.8 mm, view angle: 108° (Diagonal), 91° (Horizontal), 50° (Vertical) |
Minimum Illumination | 0.5 Lux @(F2.2, AGC ON), 0 Lux with IR |
Lens Mount | M12 |
Day & Night | IR-cut filter with auto-switching |
DNR | 3D DNR |
Night Vision | 12 m |
Video & Audio | |
Max. Resolution | 1920 × 1080 |
Frame Rate | Max: 25 fps; Self-Adaptive during network transmission |
Video Compression | H.265 |
H.265 Type | Main Profile |
Video Bit Rate | Ultra-HD; Hi-Def; Fluent. Adaptive bit. |
Audio Bit Rate | Self-Adaptive |
Max. Bitrate | 1 Mbps |
Function | |
Smart Alarm | AI Person Detection |
Two-way Talk | Supports |
General Function | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
Network | |
Standard | IEEE802.11b, 802.11g, 802.11n |
Frequency Range | 2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth | Supports 20 MHz |
Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
Transmission Rate | 11b: 11Mbps, 11g : 54Mbps, 11n: 72Mbps |
Wi-Fi Pairing | AP pairing |
Protocol | EZVIZ cloud proprietary protocol |
Interface Protocol | EZVIZ cloud proprietary protocol |
Storage | |
Local Storage | MicroSD card (Max. 256GB) |
Cloud Storage | EZVIZ Cloud Storage |
General | |
Operating Conditions | -10 ºC ~ 45 ºC (14 °F ~ 113 °F ), Humidity 95% or less ( non-condensing) |
Power Supply | DC 5V / 1A |
Power Consumption | MAX. 3.0 W |
Dimensions | 53.89 x 53.89 x 90.3 mm (2.12 x 2.12 x 3.56 inch) |
Packaging Dimensions | 91.5 x 87.5 x 149 mm (3.60 x 3.44 x 5.87 inch) |
Net Weight | 78 g (2.75 oz) |
Weight (With Package) | 305 g (10.76 oz) |
In the box: | |
In the box: | – C1HC Camera – USB Cable – 3-Meter Power Adapter – Foam Sticker – Metal Plate – Base – Drill Template – Screw Kit – Regulatory Information – Quick Start Guide |
Certifications: | |
Certifications: | FCC / UL / CE / RoHS / WEEE / REACH |
