Description
Datasheet: DP1C
Quick Start Guide: DP1C
Installation
- Compatible Peephole Diameter: 16.5 ~ 50 mm (0.65 ~ 1.97 inch)
- Compatible Door Thickness: 35 ~ 105 mm (1.38 ~ 4.13 inch)
Camera
- Sensor: 1/3″ Progressive Scan CMOS
- Lens: 2.2mm @ F2.4, view angle: 104° (horizontal / vertical), 136° (diagonal)
- Day / Night Switch: ICR infrared filter
- IR Distance: Max. 3 m (10ft.)
- Max. Resolution: 720P / 1MP
PIR Detection
- Angle: 100°
- Distance: Max. 3 m (10ft.)
- Sensitivity: Adjustable
Interface
- Storage Interface: MicroSD card slot supports up to 128 GB
- Audio Input: Built-in highly sensitive microphone
- Audio Output: Built-in high-power speaker
- Buttons: Doorbell button, power button, Screen wake up button
Network
- Face Detection: Supports
- Intelligence Alarm: PIR person detection
- Protocol: EZVIZ cloud proprietary protocol
- Video Intercom: Local and remote video intercom
- General Function: Cloud video encryption and image encryption
Wireless
- Wi-Fi Standard: IEEE802. 11b/g/n
- Frequency Range: 2.4 GHz ~ 2.4835 GHz
- Channel Bandwidth: Supports 20 MHz
- Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
- Transmission Rate: 11b: 11 Mbps, 11g: 54 Mbps, 11n: 144 Mbps
General
- Certifications: UL / FCC / CE / WEEE / REACH / RoHS
- Screen: 4.3” Colour Screen
- Operating Conditions: -10°C to 45°C (14°F to 113 °F )
- Humidity: 95% or less (non-condensing)
- Power Supply: DC 5V (±10%)
- Power Consumption: Max 2.2W
- Screen & Base Dimensions: 115.5 x 85.5 x 24.5 mm (4.55 x 3.37 x 0.96 inch)
- Camera Dimensions: 71 x 71 x 48.3 mm (2.80 x 2.80 x 1.90 inch)
- Weight: 343 g (12.1 oz)
- Colour: Silver
