DS-1LN6U-W/CCA

Description

Datasheet: DS-1LN6U-W/CCA

General

• Core Color: 1 Blue & White/ Blue 2 Orange & White/ Orange,3 Green & White/ Green 4 Brown & White/ Brown,
• Packing: Carton
• Carton Dimension: 41x41x24cm
• Packing Length: (305±1.5)m
• Rip-Cord: Yes
• Drain Wire: No
• Sheath Physical Properties
  • Before Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150
  • Aging Period(℃×hrs) 100℃×24h×7d
  • After Aging ,Tensile Strength(Mpa) ≥12.5, variance ratio:±25%, Elongation(%) ≥125, variance ratio:±20%,Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks
• Electrical Characteristics (20℃): 1.0-100.0MHz Impedance(Ω) 100±15,100 – 250MHz Impedance(Ω) 100±25,1.0-100.0MHz Delay Shew (ns/100m) ≤45,DC ResistanceΩ/100m) max 12,DC Conductor Resistance Unbalance(%) max 2,

Conductor

• Material: CCA（Copper content：27%）
• Nom.O.D.(Mm): 0.585±0.01

Insulation

• Material: Solid HDPE
• Diameter: 1.05±0.05mm

Sheath

• Thickness: 0.50±0.05 mm
• External O.D.: 6.0±0.30 mm
• Surface: Clean, Frap, Satiation
• Material: FR-PVC(complies RoHS)
• Color: White RAL9003

Surface Printing

• Letter Height: 2.5±0.2mm
• Color: Black
• Print Error & Space: ≤±0.5%，1m
