Description
Camera Image Sensor 1/2.8″ progressive scan CMOS Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON) Shutter Speed 1/3 s to 1/100, 000 s Slow Shutter Yes Auto-Iris No Day &Night IR cut filter Digital Noise Reduction 3D DNR WDR DWDR Angle Adjustment Pan: 0° to 355°, tilt: 0° to 70°, rotate: 0° to 355° Lens Focal length 2.8 mm, 4 mm Aperture F2.0 Focus Fixed FOV 2.8 mm, horizontal FOV 114.8°, vertical FOV 62°, diagonal FOV 135.5° 4 mm, horizontal FOV 86°, vertical FOV 46.5°, diagonal FOV 102.5° Lens Mount M12 IR IR Range Up to 30 m Wavelength 850 nm Compression Standard Video Compression Main stream:H.265/H.264 Sub stream: H.265/H.264/MJPEG H.264 Type Main Profile/High Profile/Baseline Profile H.265 Type Main Profile Video Bit Rate 32 Kbps to 8 Mbps Smart Feature-set Region of Interest 1 fixed region for main stream Image Max. Resolution 1920 × 1080 Main Stream Max. Frame Rate 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) Sub-stream Max. Frame Rate 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) Image Enhancement BLC, 3D DNR Image Setting Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser Day/Night Switch Auto, scheduled, day, night Network Alarm Trigger Motion detection, video tampering alarm, illegal login Protocols TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP General Function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark Firmware Version V5.5.70 API ONVIF (PROFILE S), ISAPI Simultaneous Live View Up to 6 channels User/Host Up to 32 users 3 levels: Administrator, Operator, and User Specification Available Model DS-2CD1123G0E-I (2.8/4mm) Client iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 Web Browser IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ Interface Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port General Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing) Power Supply 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3) Power Consumption and Current 12 VDC, 0.4 A, Max: 5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 6.5 W Ingress Protection IP67, IK10 Material Front cover: plastic, back cover & bracket: metal Dimensions Camera: Ø 111 mm × 82.4 mm (4.4″ × 3.2″) With package: 134 mm × 134 mm × 108 mm (5.3″ × 5.3″ × 4.3″) Weight Camera: Approx. 400 g (0.9 lb.) With package: Approx. 600 g (1.3 lb.)
