Description
Camera
- Image Sensor: 1/3″ progressive scan CMOS
- Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON)
- Shutter Speed: 1/3 s to 1/100, 000 s
- Slow Shutter: Yes
- Auto-Iris: No
- Day &Night IR: cut filter
- Digital Noise Reduction: 3D DNR
- WDR Digital: WDR
- Angle Adjustment Pan: 0° to 355°, tilt: 0°to 70°
Lens
- Focal Length: 2.8 mm, 4 mm, 6 mm
- Aperture: F2.0
- Focus: No
- FOV:
2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117°
4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 88°
6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 58° - Lens Mount: M12
IR
- IR Range: Up to 30 m
- Wavelength: 850 nm
- Compression: Standard
- Video Compression Main stream: H.265/H.264
- Sub stream: H.265/H.264/MJPEG
H.264 Type Baseline Profile/Main Profile/High Profile
H.264+ Main stream supports
H.265 Type Main Profile
H.265+ Main stream supports - Video Bit Rate: 32 Kbps to 8 Mbps
- Smart: Feature-set
- Region of Interest: 1 fixed region for main stream and sub-stream
- Max. Resolution 2560 × 1440
- Main Stream
Max. Frame Rate:
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-stream
Max. Frame Rate:
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) - Image Enhancement: BLC, 3D DNR
- Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or
web browser - Day/Night Switch: Auto, scheduled
Network
- Network Storage NAS (NFS, SMB/CIFS)
- Alarm Trigger Motion detection, video tampering alarm, illegal login
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour - General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Firmware Version: 5.5.3
- API ON: VIF (PROFILE S, PROFILE G), ISAPI
- Simultaneous Live View: Up to 6 channels
- User/Host: Up to 32 users
3 levels: Administrator, Operator and User - Client i: VMS-4200, Hik-Connect, iVMS-5200
- Web Browser: IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
- Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
- Reset Button: Yes
General
- Operating Conditions: -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
- Power Supply: 12 VDC ± 25%, 5.5 mm coaxial power plug, PoE (802.3af, class 3)
- Power Consumption and Current 12 VDC, 0.4 A, Max: 5 W
- PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.13 A, Max: 7 W
- Ingress Protection: IP67, IK10
- TVS 2000V lightning protection, surge protection and voltage transient protection
- Material Metal & Plastic
- Dimensions
- Camera: Ø 111 mm × 82.4 mm ( 4.4″ × 3.2″)
- With package: 134 mm × 134 mm × 108 mm (5.3″ × 5.3″ × 4.3″)
- Weight Camera: approx. 410 g (0.9 lb.)
- With package: approx. 610 g (1.3 lb.)
