Description
Camera
- Image Sensor: 1/3″ Progressive Scan CMOS
- Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON)
- Shutter Speed: 1/3 s to 1/100, 000 s, support slow shutter
- Slow Shutter: Yes
- Auto-Iris: No
- Digital Noise Reduction: 3D DNR
- WDR: 120 dB
- Angle Adjustment: Pan: 0° to 360°, tilt: 0°to 90°, rotation: 0° to 360°
Lens
- Focal Length: 2.8 to 12 mm
- Aperture: F1.6
- Focus: Manual
- FOV
- Horizontal field of view: 98°to 28°
- Vertical field of view: 51°to 16°
- Diagonal field of view: 115°to 32°
- Lens Mount: Φ14
IR
- IR Range: Up to 30 m
- Wavelength: 850 nm
- Compression Standard
- Video Compression Main stream: H.265/H.264
- Sub-stream: H.265/H.264/MJPEG
- H.264 Type Baseline Profile/Main Profile/High Profile
- H.264+ Main stream supports
- H.265 Type Main Profile
- H.265+ Main stream supports
- Video Bit Rate: 32 Kbps to 8 Mbps
- Max. Resolution: 2560 × 1440
- Main Stream
- Max. Frame Rate
- 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- Max. Frame Rate
- Sub-stream
- Max. Frame Rate
- 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
- 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
- Max. Frame Rate
- Image Enhancement; BLC, 3D DNR
- Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
- Day/Night Switch: Auto, scheduled
Network
- Storage Support; Micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR
- Alarm; Trigger Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login
- Protocols; TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP
Interface
- Communication Interface; 1 RJ45 10M/100M self-adaptive Ethernet port
- Reset Button; Yes
General
- Operating Conditions; -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
- Power Supply; 12 VDC ± 20%, 5.5 mm coaxial power plug, PoE (802.3af, class 3)
- Power Consumption and Current: 12 VDC, 0.6 A, max. 7 W; PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 9 W
- Protection Level: IP67, TVS 2000V lightning protection, surge protection and voltage transient protection
- Material: Metal
- Dimensions: 105 mm × 105 mm × 145 mm (4.1″ × 4.1″ × 5.7″)
- Weight Camera: approx. 1035 g (2.3 lb.)
- With package: approx. 1550 g (3.4 lb.)
