| Image Sensor |
1/2.8″ Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @(F2.0, AGC ON); B/W: 0.001 Lux @(F1.2, AGC ON), 0.0028 Lux @(F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Auto-Iris |
No |
| Day & Night |
IR Cut Filter |
| Digital Noise Reduction |
3D DNR |
| Wide Dynamic Range |
DWDR |
| Angle of adjustment |
Pan: 0° to 355°, tilt: 0° to 70° |
| Focal Length |
2.8/4/6 mm |
| Aperture |
F2.0 |
| Focus |
No |
| FOV |
2.8 mm: horizontal FOV: 115°, vertical FOV: 62°, diagonal FOV: 136° 4 mm: horizontal FOV: 86°, vertical FOV: 47°, diagonal FOV: 103° 6 mm: horizontal FOV: 55°, vertical FOV: 31°, diagonal FOV: 62° |
| Lens Mount |
M12 |
| IR Range |
2.8 mm, 4 mm: 20 meters 6 mm: 30 meters |
| Wavelength |
850nm |
| Video Compression |
Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.264+ |
Main stream supports |
| H.265 Type |
Main Profile |
| H.265+ |
Main stream supports |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Audio Compression (-S) |
G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate (-S) |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Behavior Analysis |
Line crossing detection, intrusion detection |
| Region of Interest |
1 fixed region for main stream |
| Max. Resolution |
1920 × 1080 |
| Main Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240 |
| Image Enhancement |
BLC/3D DNR |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser |
| Target Cropping |
No |
| Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by alarm in (-S) |
| Network Storage |
Support built-in micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Firmware Version |
V5.5.3 |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI |
| Simultaneous Live View |
Up to 6 channels |
| User/Host |
Up to 32 users 3 levels: Administrator, Operator and User |
| Client |
iVMS-4200, Hik-Connect, iVMS-5200 |
| Web Browser |
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ |
| Audio (-S) |
1 input (line in), 1 output (line out), mono sound |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Alarm (-S) |
1 input, 1 output |
| Video Output |
No |
| On-board Storage |
Built-in micro SD/SDHC/SDXC slot, up to 128 GB |
| SVC |
No |
| Reset Button |
Yes |
| Wireless Standards |
IEEE 802.11b/g/n |
| Frequency Range |
2.4 GHz to 2.4835 GHz |
| Channel Bandwidth |
20/40MHz |
| Protocols |
802.11b: DQPSK, DBPSK, CCK 802.11g/n: 64-QAM, 16-QAM, QPSK, BPSK |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transfer Rates |
11b: 11Mbps, 11g: 54Mbps, 11n: 65Mbps |
| Wireless Range |
50 m |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Operating Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, PoE (802.3af, class 3) |
| Power Consumption and Current |
PoE: (802.3af, 36V-57V), 0.2 A to 0.1 A, max. 6.5W 12 VDC, 0.4 A, max. 5W |
| Protection Level |
IP67 |
| Material |
Front cover: plastic, base: metal |
| Dimensions |
Camera: Φ 111 × 82.4 mm (Φ 4.4″ × 3.2″) With package: 135× 135 × 110 mm (5.3″ × 5.3″ × 4.3″) |
| Weight |
Camera: approx. 400 g (0.9 lb.) With package: approx. 500 g (1.1 lb.) |
