Description
Datasheet: DS-2CE79U1T-IT3ZF
User Manual: DS-2CE79U1T-IT3ZF
Camera
- Image Sensor: 8.29 megapixel progressive scan CMOS
- Max. Resolution: 8MP
- Min. Illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time: PAL: 1/12.5s to 1/50, 000 s,NTSC: 1/15 s to 1/50, 000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360°
Lens
- Lens Type: Autofocal Lens
- Focal Length & FOV: 108.1° to 45.6°
- Lens Mount: Φ 14
- Image Settings: Brightness, Sharpness, DNR, Mirror, Smart IR, HLC
- Frame Rate
- TVI: 8MP@12.5fps, 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps,,2MP@30fps
- CVI: 8MP@12.5fps, 8MP@15fps
- AHD: 8M@12.5fps, 8M@15fps
- CVBS: 960H P/N
- Day/Night Mode: Auto/Color/BW (Black and White)
- Wide Dynamic Range (WDR): Yes
- Image Enhancement: Yes
- White Balance: Auto/Manual
- AGC: Yes
Interface
- Video Output: TVI/AHD/CVI/CVBS
General
- Material: Metal
- Dimension: 134.3 mm × 123.86 mm × 110.24 mm (5.29″ × 4.88″ × 4.34″)
- Weight: Approx. 580 g (1.28 lb.)
- Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- Communication: Up the coax, Protocol: HIKVISION-C (TVI output)
- Power Supply: DC12V
- Consumption: Max. 8.6W
- IR Range: 30~60m
Approval
- Protection: 1P67
