Description
PoE Power Supply
- PoE Standard: IEEE 802.3af, IEEE 802.3at
- PoE Power Pin Ports for long-distance transmission (9-16) support 8-core power supply,Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply.Ports for close-range transmission (1-8) support 4-core power supply.Ethernet cable 1/2/3/6 provide power supply.
- PoE PortPorts 1 to 16
- Max. Port Power30 W
- PoE Power Pudget130 W
- Max. Power Consumption150 W
Network Parameters
- Port Number16 × 100 Mbps PoE ports, 1 × 1000 Mbps RJ45 port, and 1 × 1000 Mbps SFP fiber optical port
- Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding ModeStore-and-forward switching
- Working ModeStandard mode (default); Extend mode
- High priority portsPorts 1 to 8
- Ports for Long-Distance TransmissionPorts 9 to 16
- MAC Address Table4 K
- Switching Capacity7.2 Gbps
- Packet Forwarding Rate5.356 Mpps
- Internal Cache2.75 Mbits
General
- ShellMetal material
- Gross Weight2.58 kg (5.69 lb)
- Net Weight1.8 kg (4.0 lb)
- Dimension (L × H × D)266 mm × 44.5 mm × 220.8 mm (10.5” × 1.8” × 8.7”)
- Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Storage Humidity5% to 95% (no condensation)
- Power Supply100 to 240 VAC, 50/60 Hz, Max. 2.5 A
- Power Consumption in Idle20 W
Approval
- EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014,
EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015);
RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016) - SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD
(EN 60950-1:2005 + Am 1:2009 + Am 2:2013) - ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
