Description
Datasheet : DS-3E2510P
User Manual : DS-3E2510P
Key Feature | |
---|---|
QoS |
Flow classification based on L2~4 protocols CAR flow limit 802.1P/DSCP priority re-labeling SP, WRR, and âSP+WRRâ Congestion avoidance mechanisms like Tail-Drop and WRED Flow monitoring and flow shaping |
STP |
802.1D (STP), 802.1W (RSTP) and 802.1S (MSTP) BPDU protection, root protection, and loopback protection |
Multicast |
IGMP v1/v2/v3, snooping IGMP Fast Leave Multicast group strategy and quantity limitation |
Security |
L2/L3/L4 ACL flow identification and filtration DDoS attack prevention, TCPâs SYN Flood attack prevention, UDP Flood attack prevention, etc Broadcast/multicast/unknown unicast storm-control Port isolation Port security, and âIP+MAC+portâ binding |
Management Maintenance |
Console, Telnet, SSH2.0, Web SNMP v1/v2/v3 TFTP RMON |
Network Parameters | |
Port Number | 8 x 10/100/1000Base-T PoE ports, 2 1000Base-X SFP ports, 1 Console port |
MAC Address Table | 8K |
Switching Capacity | 20Gbps |
Packet Forwarding Rate | 15Mpps |
PoE Power Supply | |
PoE Standard | IEEE802.3af, IEEE802.3at |
PoE Power Budget | 125W |
Performance Parameter | |
VLAN Capability | 4K VLAN; GVRP; QinQ; Private VLAN |
Environment | |
Working Temperature | 0â-45â |
Working Humidity | 5%-95% non-condensing |
General | |
Dimension (W Ă H Ă D) | 280 mm Ă 45 mm Ă 179 mm |
Power Supply</ | ACïŒ100V-240VïŒ50Hz±10% |
Power Consumption | <15W |
