Description
Decoding
- Recording Resolution : 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Decoding Format : H.265/H.265+/H.264/H.264+/MPEG4
- Synchronous Playback : 16-ch
- Capability : 2-ch @ 8 MP (25fps) / 4-ch @ 4MP (30fps) / 8-ch @ 1080p (30fps)
External Interface
- Two-Way Audio Input : 1-ch, RCA (2.0 Vp-p, 1kΩ)
- Network Interface : 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- USB Interface : Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
- Alarm In/Out : 4/1
General
- Power Supply : 12 VDC,≤ 40 W
- Consumption (Without HDD) : ≤15 W
- Working Temperature : -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity : 10 to 90 %
- Dimensions (W × D × H) : 385 × 315× 52 mm (15.2″ × 12.4″ × 2.0″)
- Weight (Without Hard Disk) : ≤ 1 kg (2.2 lb)
Video/Audio Input
- Incoming/Outgoing Bandwidth : 160 Mbps ,256 Mbps
- IP Video Input : 32-ch
Video/Audio Output
- VGA Output : 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- HDMI Output : 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Audio Output : 1-ch, RCA (Linear, 1 KΩ)
Network Management
- Network Protocols : TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Hard Disk
- SATA : 2 SATA interfaces
- Capacity : Up to 6 TB capacity for each HDD
