Description
| LED Module | |
|---|---|
| Module type: | Surface mounted trinity LED |
| Pixel pitch: | 1.27 mm |
| Resolution (W × H): | 120 × 90 |
| Dimensions (W × H): | 152.48 × 114.36 mm |
| Optical | |
| Brightness (nits): | 400 |
| Color temperature: | 3000 to 6000 adjustable |
| Viewing angle: | Horizontal 160°, vertical 160° |
| Recommended viewing distance: | ≥ 2 m |
| Brightness uniformity: | ≥ 97% |
| Center distance deviation of LED: | < 3% |
| Color uniformity: | ≤ ± 0.003 Cx, Cy |
| Contrast: | ≥3000 : 1 |
| LED Unit | |
| Modules component (W × H): | 4×3 |
| Resolution (W × H): | 480 × 270 |
| Pixel density: | 619,350 pitch/ m2 |
| Screen area: | 0.2093 m2 |
| Aspect ratio: | 16 : 9 |
| Electrical | |
| Max. consumption (W/m2): | 850 |
| Average consumption (W/m2): | 270 |
| Power supply: | 100 to 240 VAC ± 15% |
| Processing Performance | |
| Driving mode: | Constant current driving |
| Frame frequency: | 60 Hz |
| Refresh rate: | 3, 840 Hz |
| Processing depth (bit): | 16 |
| Grey level (bit): | 65, 536 |
| Color: | 281.4 trillion |
| Brighness control: | Auto/Manual |
| General | |
| Working hours: | ≥ 100,000 h |
| Working temperature: | -10 to 40 o C (14 to 104 o F) |
| Storage temperature: | -20 to 60 o C (-4 to 140 o F) |
| Working humidity: | 10 to 80 % (non-condensing) |
| Storage humidity: | 10 to 85% (non-condensing) |
| Dimensions (W × H × D): | 609.9 × 343.1 × 75 mm (24.0 × 13.5 × 2.95 inch) |
| Weight: | ≤ 37.3 kg (82.2 lb) |
| Ingress protection: | IP5X |
| Material: | Aluminium |
