Description
LED Module
Module type: Surface mounted trinity LED
Pixel pitch: 1.906 mm
Resolution (W × H): 80 × 60
Dimensions (W × H): 152.48 × 114.36 mm
LED Unit
Modules component (W × H): 4 × 3
Resolution (W × H): 320 × 180
Screen area: 0.2093 m
Pixel density: 275, 267 pitch/ m2
Aspect ratio: 16 : 9
Optical
Brightness (nits): 800
Color temperature: 3000 to 10000 adjustable
Viewing angle Horizontal: 160°, vertical 160°
Recommended viewing distance: ≥ 2 m
Center distance deviation of LED: < 3%
Brightness uniformity: ≥ 97%
Color uniformity: ≤ ± 0.003 Cx, Cy
Contrast: ≥3000 : 1
Electrical
Max. consumption (W/m2): 850
Average consumption (W/m2): 275
Power supply: 100 to 240 VAC ± 15%
Processing Performance
Driving mode: Constant current driving
Frame frequency: 60 Hz
Refresh rate: 3, 840 Hz
Processing depth (bit): 16
Grey level (bit): 65, 536
Color: 281.4 trillion
Brighness control: Auto/Manual
General
Working hours: ≥ 100,000 h
Working temperature: -10 to 40 º C (14 to 104 º F)
Storage temperature: -20 to 60 º C (-4 to 140 º F)
Working humidity: 10 to 80 % (non-condensing)
Storage humidity: 10 to 85% (non-condensing)
Dimensions (W × H × D): 609.9 × 343.1 × 75 mm (24.0 × 13.5 × 2.95 inch)
Weight: ≤ 37.3 kg (82.2 lb)
Ingress protection: IP5X
Material: Aluminium
