Description
| Display | |
|---|---|
| Display Type: | LED-Backlit |
| Screen Size: | 23.6” |
| Pixel Pitch(H×V): | 0.2715mm ×0.2715mm |
| Max Resolution: | 1920×1080 |
| Brightness: | 250cd/m2 (Typical) |
| Contrast: | 1000:1(Typical) DCR 30,000,000:1 |
| Response Time: | 5ms |
| Color: | 16.7M |
| Viewing Angle: | Horizontal 170°, Vertical 160° |
| Audio | |
| Audio Input : | 1x 3.5 mm mini-jack , 1x RCA type |
| Speaker: | 2*2W |
| Interfaces | |
| HDMI Input: | 1 |
| VGA Input: | 1 |
| BNC Input: | 1 |
| BNC Output: | 1 |
| Mounting | |
| VESA: | 100mm × 100mm |
| General | |
| Consumption: | < 30W(on) < 0.5W(Standby) |
| Power Supply: | AC 100~240V |
| Operation Temperature: | 0°C ~ 40 °C |
| Operating Humidity: | 10%~85% (No Condensation) |
| Storage Temperature: | -20°C ~ 60°C |
| Storage Humidity: | 5%~95% (No Condensation) |
| Dimension (W×H×D): | 561x339x218.5 (mm) 22.1×13.3×8.6(inch) |
| Weight: | 6.0Kg(Gross weight) , 5.1(Net weight) |
| Package Dimension: | Power cord x 1, VGA cable x 1, User manual x 1, warranty card x 1, base bracket x 1 |
