Description
LCD Screen
- Diagonal screen size: 75″
- Backlight: LED Backlight
- Max. resolution: 4K(3840 × 2160)
- Brightness: 350 cd/m²
- Contrast: 3000: 1
- Response time: 4 ms
- Pixel pitch: 0.429 mm × 0.429 mm
- Color: 10 bit
- Viewing Angle: Horizantal 178°, vertical 178º
- Hue: 92%
- Active Area: 1649.66 × 927.94 mm
Touch
- Touch mode: IR/Optical touch
- Glass Thickness: 4mm
- Glass transmittance: ≥ 92%
- Touch point: 10-point touch
- Input method: Finger or touch pen
- Touch response time: ≤ 8ms
- Touch precision: ±2mm
- Min. touch object: Non-transparent object with diameter ≥ 6mm
- Anti-glare: Yes
- Video input
- 4, HDMI interface
- 2, VGA interface
- 1, YPbPr interface
- 1, AV-IN interface
- Audio input: 3, AUDIO-IN interface
- Audio output
- EARPHONE
- SPDIF-OUT
- Network: 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- USB interface
- 3, USB (PC+ Android) on front panel
- 2, Android-USB on side panel
- 1, TOUCH-USB
- RS-232 interface: 1
General
- Casing Material: Aluminum alloy
- Color of Casing: Black
- Wall-mounting Hole (VESA): 600 × 400 mm
- Wall-mounting Screw: 4 × M8
- Power Supply: 100 to 240 VAC, 50/60Hz
- Power Consumption: ≤ 350 W
- Standby Power Consumption: ≤ 1.5 W
- Working Temperature: 0 to 40 º C (0 to 104 º F)
- Working Humidity: 20 to 80 % (non-condensing)
- Dimensions (without base): 1798.5 × 1110.6 × 79.6 mm (70.8″ × 43.7″ × 3.1″)
- Packing Dimensions: 2040 × 1285 × 345 mm (80.3″ × 50.6″ × 13.6″)
- Gross Weight (with packing): ≤ 91 kg (200.6lb)
- Net Weight: ≤ 73 kg (160.9 lb)
