Description
Datasheet: DS-D5SC3B-B
Quick Start Guide: DS-D5SC3B-B
Display
- Resolution: 1080P/4K
Built-in System
- Memory: 512 MB
- Built-in Storage: 4 GB
- net card: Built in Gigabit NIC, supporting 2.4G/5G.
Interface
- Power Interface: Type-C, support CC communication and automatically switch charging direction, achieving 60W fast charging for laptops by adapter and 5V/500mA charging for mobile phones from laptops.
Power
- Power Consumption: 2.8 W
- Rated Power: 5 V/900 mA
Working Environment
- Working Temperature: 0℃~40℃
- Working Humidity: 10%~95% RH
General
- Product dimensions: 189 × 58 × 17 mm
- Package Dimensions (W × H × D): 235 × 90 × 30 mm
- Net Weight: 90 g
- Gross Weight: 210 g
- Packing List: Host × 1, Manual × 1, USB Type-A/Type-C adapter × 1
- Frame Rate: 30 fps
- Transmission Delay: ≤ 350 ms
- Wireless Transmission Protocol: IEEE 802.11 a/g/n/ac
- Encryption: AES
- NFC: ISO/IEC 14443-A protocol, 13.56 MHz, 106 Kbps
- Audio Parameters: 48000Hz sampling rate, 16 bit depth, ACC encoding, dual channel
- Video Parameters: 10 bit color depth, H.264 encoding format
- USB Protocol: Support USB 2.0
