Description
| System Parameters | ||
|---|---|---|
| Card Reading Distance: | EM Card: ≤100 mm (≤3.94″) Mifare Card:≤50 mm (≤1.97″) | |
| ID Settings: | Setting by the DIP Switch on the Main Board | |
| Processor: | 32-bit | |
| Device Interfaces | ||
|---|---|---|
| Communication Mode: | RS485/Wiegand（ Set via DIP Switch） | |
| General | ||
|---|---|---|
| Radio Frequency Standard: | ISO 14443-A | |
| Key Board: | No Keypad (DS-K1108E and DS-K1108M) Keypad with 12 Keys (0~9, *, #) (DS-K1108EK and DS-K1108MK) |
|
| Prompt: | Buzzer | |
| LED Indicator: | Power Indicator; Status LED Indicator | |
| Protection Level: | IP 65 Water-Proof | |
| Installation: | Wall Mounting with/without Gang Box | |
| Temper-Proof: | Support | |
| Working Humidity: | 10% to 90% (Non-Condensing) | |
| Working Temperature : | -20°C to +65°C (-4°F to +149°F) | |
| Dimensions (L×W×H): | 123mm × 88mm × 21mm (4.84″ × 3.46″ × 0.83″) | |
