| System Parameters | ||
|---|---|---|
| Fingerprint Recognition Duration: | < 1 s | |
| Operation System: | Linux | |
| Storage: | 3,000 cards, 100,000 events, 150,000 attendance records | |
| FRR (False Rejection Rate): | ≤0.01% | |
| Card Reading Distance: | 1 ~ 5cm | |
| iVMS-4200: | Support | |
| FAR (False Accept Rate): | ≤0.001% | |
| Fingerprint Comparing Mode: | 1:1 and 1:N, N=3000 | |
| Card Reading Mode: | Supports Mifare Card, Including Cards with Special Shapes; Supports Reading Card in Metal Environment | |
| Card Reading Response Duration: | < 1 s | |
| Fingerprint Recognizer: | Optical Fingerprint Recognizer Module | |
| Fingerprint Capacity: | 3,000 | |
| Device Interfaces | ||
| Transmission Rate: | LAN: 10/100 Mbps Self-adaptive | |
| Wi-Fi: | Support | |
| USB Interface: | USB2.0, Type A | |
| General | ||
| LCD Screen: | 2.8-inch 320 x 240 LCD-TFT Display Screen | |
| Key Board: | Physical Keys (No Back Light) | |
| Lithium Battery: | Lithium Battery 2000mAh | |
| Power Supply: | 12 VDC/1 A | |
| Audio: | 1 Buzzer and 1 Loudspeaker | |
| Appearance Color: | Black (Included), Gold (Optional), Silver (Optional), White (Optional) | |
| Installation: | Surface Mounting, Metal Door Mounting, Desk Stand | |
| Application Situation: | Indoor | |
| Working Humidity: | 10% to 90% (Non-Condensing) | |
| Working Temperature : | -10° C to 55° C (14° F to 131° F) | |
| Dimensions (L×W×H): | 140mm × 155mm × 30mm (5.51″ × 6.01″ × 1.18″) | |
