System Parameters | ||
---|---|---|
Storage: | 100,000 cards(200,000 expandable) 300,000 events(600,000 expandable) | |
Capacity: | 16M | |
Processor: | 32-bit | |
Device Interfaces | ||
Accessible Card Reader: | 4 Card Readers (RS485 Interface) and 4 Card Readers (Wiegand Interface) Connectable | |
Uplink Communication Interface: | TCP/IP Network Interface and RS-485 Interface | |
Downlink Communication Interface: | RS-485 and Wiegand (W26/W34) | |
Output Interface: | Lock Relay×2, Alarm Relay×4 | |
Input Interface: | Alarm Input×4,Door Sensor×2,Exit Button×2,Case Input×4,Tamper Alarm×1 | |
General | ||
Working Voltage: | DC 12V/1A | |
Power Consumption: | ≤4W(Without Load); ≤100W(with Load) | |
LED Indicator: | Power Supply Status, Communication Status, Working Status | |
Certification: | CE, FCC | |
Working Humidity: | 10% to 90% (Non-Condensing) | |
Working Temperature : | -20°C to +65°C (-4°F to +149°F) | |
Dimensions (L×W×H): | 370mm x 345mm x 90 mm (14.6” x 13.6” x 3.5″) |
