Description
Datasheet: DS-K2604T
User Manual: DS-K2604T
System Parameters
- Capacity: 100,000 cards 300,000 events
Device Interface
- Communication: TCP/IP, RS-485, Wiegand (W26/W34)
- Accessible Card Reader: 8 card readers (RS-485 interface), and 4 card readers (Wiegand interface)
- LED Indicator: Power supply status, Communication status, and work status
- Built-In Clock: Support
General
- Working Temperature: -20 °C to +65 °C (-4 °F to +149 °F)
- Working Humidity: 10% to 90% (Non-condensing)
- Power Supply:≤100W
- Working Voltage: DC 12V/1A
- Power Dissipation (Without Load): ≤4W
- Dimensions (L×W×H): 373 mm × 345 mm × 98 mm (14.7″ × 13.6″ × 3.6″)
- Certification: CE, FCC, CB
- Processor: 32-Bit
- Storage: 32M
- Input Interface: Alarm input × 4, door contact × 4, exit button × 4, case input × 8, tamper alarm × 1
- Output Interface: Lock relay × 4, alarm relay × 4
