Description
| Working Temperature | -10°C to +55°C (14°F to 131°F) |
| Working Humidity | 0 to 95% (Relative Humidity) |
| Working Current | 12V/500mA 24V/250mA |
| LED Indicator | Dry Contact Signal Output, Support Maximum Power Rate of 3A, NO Output While Locking and NC Output While Unlocking |
| Dimension Of Lock Body (L×W×H) | 240×49×25.5mm (9.45×1.93×1.00″) |
| Dimension Of Armature Plate (L×W×H) | 180×38×11mm (7.1×1.5×0.4″) |
| Maximum Thrust | 300kg Linear Thrust |
| Input Voltage | DC12V/DC24V |
| Suitable Door | Red (Door is Unlocked) Green (Door is Locked) |
| Surface Temperature | Wooden Door, Glass Door, Metal Door, Fireproof Door |
| Shell | Hard Anodizing Electroplating Operated |
| Lock Body | Eco-friendly Zinc with Electroplating Operated |
| Armature Plate | Eco-friendly Zinc with Electroplating Operated |
| Weight | 2.1kg(4.63lb) |
