DS-K7P05
Availability: not in Stock

DS-K7P05

logo-2

Key Features

  • Dimension (L×W×H): 86×86×28.9mm(3.39×3.39×1.14″);
  • Structure: aluminum alloy panel, metal button;
  • Current Rating: 3A@36VDC Max;
  • Output Contact: NO/NC/COM Contact;
  • Aging Test: already passed 500 thousand times aging test;
  • Suitable Doors: hollow doorframe and embedded-electric box;
  • Working Temperature: -10°C to +55°C (14°F to 131°F);
  • Working Humidity: 0 to 95% (relative humidity);
  • Panel: aluminum panel with sandblast;
  • Product Weight: 0.25kg (0.55lb).

Description

Datasheet: DS-K7P05

General
Output Contact: NO/NC/COM Contact
Aging Test: already passed 500 thousand times aging test
Structure: stainless steel panel, metal button, metal bottom case
Current Rating: 3A@36VDC Max
Accessories: equipped with metal bottom case
Suitable Doors: all kinds of narrow doorframes
Panel: brushed stainless steel panel
Bottom Case: polished zinc alloy with chromium electroplating
Working Humidity: 0 to 95% (relative humidity)
Working Temperature : -10° C to 55° C (14° F to 131° F)
Dimensions (L×W×H): 86mm × 50mm × 44mm(3.39” × 1.97” × 1.73″)
Weight: 0.14kg (0.31lb)
