Description
General | ||
---|---|---|
Output Contact: | NO/NC/COM Contact | |
Aging Test: | already passed 500 thousand times aging test | |
Structure: | stainless steel panel, metal button, metal bottom case | |
Current Rating: | 3A@36VDC Max | |
Accessories: | equipped with metal bottom case | |
Suitable Doors: | all kinds of narrow doorframes | |
Panel: | brushed stainless steel panel | |
Bottom Case: | polished zinc alloy with chromium electroplating | |
Working Humidity: | 0 to 95% (relative humidity) | |
Working Temperature : | -20°C to +65°C (-4°F to +149°F) | |
Dimensions (L×W×H): | 87.7mm × 87.7mm × 44mm(3.46”×3.46”×2.13″) | |
Weight: | 0.23kg (0.51lb) |
