Description
Data sheet: DS-KD8002-VM
User Manual: DS-KD8002-VM
Display Parameters
- Size: 3.5-Inch
- Operation Method: Physical button
- Type: Colorful TFT LCD
Video Parameters
- Supplement Light: Visible Light Supplement
- Lens: 1
- FOV: /
- Pixel: 1280 × 720
Audio Parameters
- Audio Quality: Noise suppression and echo cancellation
Network Parameters
- Communication Protocol: TCP/IP, RSTP
- Wired Network: 10/100 Mbps self-adaptive Ethernet
- Wi-Fi: /
- Bluetooth: /
Device Interfaces
- Network Interface: 1 RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface
- Exit Button: 1
- Lock Control: 1
- Door Contact Input: 1
- Power Interface: 1
General
- Button: 14
- Installation: Surface mounting
- Indicator: 0
- Protective Level: IP65
- Power Supply Method: 12 VDC
- Working Temperature: -40° C to +60° C (-40° F to 140° F)
- Working Humidity: 10% to 90%
- Dimensions: 418 mm × 145 mm × 61 mm (16.5″ × 5.7″ × 2.4″)
- Battery: /
- Application Environment: Outdoor
- Power Consumption: ≤15 W
