Description
Datasheet: DS-KM8301
User Manual: DS-KM8301
System Parameters
- Processor: High-Performance Embedded SOC Processor
- Operation System: Embedded Linux Operation System
Network Parameters
- Ethernet: 10/100/1000 Mbps Self-Adaptive Ethernet
- Network Protocol: TCP/IP, RTSP
Device Interfaces
- Network Interface: 1 RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface
- I/O Input: 4 On-Off Input
- I/O Output: 2 On-Off Output, 2 Relay Output
- RS-485: 2 RS-485 Half-Duplex Port
- USB: 1 USB Interface for Inserting U-Disk
General
- Power Supply: 12 VDC
- Power Consumption: ≤10 W
- Working Temperature: -10° C to + 55° C (14° F to 131° F)
- Working Humidity: 10% to 90%
- Certification: FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
- Dimensions(L × W × H): 436 mm × 215 mm × 67 mm (17.2″ ×8.5″ × 2.6″)
- Material: Plastic
