Description
System Parameters
- Flash: 32 Gb
- RAM: 256 Gb
- Operation Method: Single-button
- Operation System: Embedded Linux operating system
Video Parameters
- Camera: 2 MP HD camera
- Night Vision: Low illumination. IR supplement mode: 9.84 ft (3 m)
- BLC: Supported
- DNR: Supported
- WDR: 120 dB
- Field of View: Horizontal: 129°, vertical: 75°
- Video Compression: Standard H.264
- Stream
- Main stream: 1080p @ 30 fps, 720p @ 25 fps
- Sub-stream: D1 @ 25 fps
- Resolution
- Main stream: 1920 x 1080p, 720p
- Sub-stream: 704 x 576
- Motion Detection: Supported
- Anti-Flicker Frequency: 50 Hz, 60 Hz
Audio Parameters
- Audio Intercom: Two-way audio communication
- Audio Input: Built-in omnidirectional microphone
- Audio Output: Built-in loudspeaker
- Audio Compression Standard: G.711u
- Audio Compression Rate: 64 Kbps
- Audio Quality: Noise suppression and echo cancellation
Network Parameters
- Wired Network: 10/100 Mbps Ethernet
- Network Protocol: TCP/IP, RTSP
Access Control Parameters
- Reading Frequency: 13.56 MHz
- Card Type: Mifare
- Relay: 2
Interfaces
- RS-485: 1
- Wi-Fi: 2.4 GHz Wi-Fi
- Debugging Port: 1
- TF Card: Up to 128 Gb
- Alarm Input: 4
- Grounding: 1
- Tamper Switch: 1
- Physical Buttons: 1
General
- Protection Level: IP65, IK8
- Indicators: 3
- Power Supply: IEEE802.3af, standard PoE, 12 VDC
- Power Consumption: < 10 W
- Working Temperature: -40° to 127.4° F (-40° to 53° C)
- Working Humidity: 10 to 95%
Installation Surface mounting included
- Dimensions (L x W x H): 6.85″ x 3.58″ x 1.14″ (174 mm x 91 mm x 29 mm)
