Description
Specifications
- Capacity: 1200VA/720W
- Rated Input Voltage: 220/230VAC
- Input Voltage Range: 140-300VAC
- Frequency: 40-65 Hz
- Input: Input Power Cord with customized power plug
- Output Voltage: +/-10% (Battery mode)
- Frequency: 50Hz+/-1Hz (Battery mode)
- Output Waveform: Bat mode(simulated sine wave),AC mode (sine wave)
- Rear Output Sockets: 4* Universal
- Cold Start Provision (0-100% Load): Press On/ Off Switch
- Transfer Time: Typical 3-4 ms
- Back Up Mode: Beeps every 10 seconds
- Low Battery: Beeps every 1 seconds
- Overload: Beeps every 0.5 seconds (shutdowns immediately > 120% load)
- AC Mode/ Back Up Mode/ Fault: Green LED/ Yellow LED flashes/ Red LED
- Protections: Battery over charge/ over discharge, short Circuit, Surge protection
- Power saver function: Available
- Battery Specifications: 24VDC/7.5Ah/2no
- Environment: 0-40°C,0-90% RH Non Condensing
